IBX60-8J6W

Technical specifications

Embed PC, Intel Celeron J6412 CPU processor, up to 16GB DDR4-2666/2933/3200, 2xHDMI,1xLVDS/eDP, 2xGbit LAN, 6xCOM, 7xUSB 2.0, 3xUSB 3.0, 1x GPIO (optional), 2x M.2, 1xMini PCIe, 1xSATA, 1x SATA 3.0, 1x M.2 SATA, 1xmSATA, expandable with 2xCOM, 2xLAN, 2xPoE, 2xUSB (optional), operating temperature -20°C to +60°C

Documentation

iROBO-23403-24T1

Industrial Embedded PC IBX60-8J6W by IPC2U

The IBX60-8J6W is a reliable and flexible Industrial Embedded PC from IPC2U, powered by an Intel Celeron J6412 CPU processor. Equipped with up to 16GB DDR4-2666/2933/3200 RAM and a wide range of interfaces such as 2xHDMI, 1xLVDS/eDP, 2xGbit LAN, 6xCOM, 7xUSB 2.0, 3xUSB 3.0, 1x GPIO (optional), 2x M.2, 1xMini-PCIe, 1xSATA, 1x SATA 3.0, 1x M.2 SATA, and 1xmSATA, this Industrial Embedded PC delivers outstanding performance and connectivity for your applications.

The IBX60-8J6W is extremely robust and reliable, featuring an operating temperature range of -20°C to +60°C. It is ideally suited for applications in automation technology, logistics, process control, and many other fields. The Embedded PC can be easily expanded to meet the individual requirements of your applications. Optionally, the IBX60-8J6W can be equipped with additional interfaces such as 2xCOM, 2xLAN, 2xPoE, and 2xUSB.

Easy to install, the IBX60-8J6W can be utilized in a wide range of applications. With its numerous interfaces and robust design, this Industrial Embedded PC is a powerful and reliable system for your applications.

Discover the reliable and flexible Industrial Embedded PC, IBX60-8J6W by IPC2U, and optimize your applications. Contact us today to learn more about the IBX60-8J6W and place your order for this high-performance Embedded PC.

Why IPC2U?

Value Added Distributor

With our many years of expertise in the distribution of IT hardware products for the industry, we offer you real added value in your projects.

Semi- and Full-Custom-Designs

We offer you semi- and full-custom designs of high-quality products in various performance classes with diverse input/output configurations, processor classes, and other hardware components.

ISO9001 certificated

The development and manufacturing are carried out using state-of-the-art equipment while adhering to the highest ISO9001 quality standards.

Product features

Industrial Embedded PC. Available with Intel Core Celeron J6412 processor.

Intel Celeron J6412 CPU
M.2 Key-M 2280 Slot for M.2 PCIe x2 (NVMe) or SATA, mSATA
Operating temperature -20°C to +60°C
Voltage Input 9-36V terminal Block connector
Optional 12V DC Jacl connector

Do you have any questions?

Our product experts will be happy to assist you.

Variety of Interfaces available.

With 2xHDMI,1xLVDS/eDP, 2xGbit LAN, 6xCOM, 7xUSB 2.0, 3xUSB 3.0, 1x GPIO (optional), 2x M.2, 1xMini-PCIe, 1xSATA, 1x SATA 3.0, 1x M.2 SATA, 1xmSATA, expandable with 2xCOM, 2xLAN, 2xPoE, 2xUSB (optional) the IBX60-8J6W offers a variety of interfaces.

Request now.

Benefit from long availability and first-class performance. Contact our product experts via form and receive non-binding advice.
